Pisgah

4.94 ( 17   )
The most capable trail hardtail we've ever created, made tougher with advanced titanium design.
Looking for Frameset? Click here.

These components are required:

Your total:
Your total:
USD

YOUR BUILD HIGHLIGHTS

THE PERFECT BALANCE

The Pisgah climbs faster, descends harder, and moves like an extension of your body. Confident geometry combined with tuned flex empowers riders to shralp corners, skip across rocks and roots, and squash brutal G-outs.

A LEGENDARY RIDE

Custom-formed tubes use variable wall thickness and cold-worked 3D shaping to optimize durability and stiffness. The Pisgah is built to take the endless abuse and embody the legendary ride of Litespeed titanium.

BUILT FOR BIG HITS

An all-new tubeset made with advanced titanium tube shaping and a unique rear-end design built around a tubular yoke increases the Pisgah's strength and stiffness where it matters, maximizing its abilities on the toughest terrain.

EXPLORE THE DETAILS

A titanium hardtail engineered for the most aggressive riding, with precision-designed joints that enhance frame strength. Smash gnarly descents, shralp loose corners, and send bigger features. The Pisgah slays any notion of what a hardtail trail bike is capable of.

  • 150mm Fork Travel
  • Superform X Titanium Tubeset
  • Tubular Titanium Yoke
  • UDH Dropout
  • Optional Sliding Titanium Dropout Upgrade
  • External Cable Routing
  • Stealth Dropper Routing
  • T47 Threaded BB
  • 29" x 2.6" Tire Clearance

Select a build kit:

Groupset SRAM Eagle GX AXS
Headset Choose From: Cane Creek Hellbender 70 or Chirs King Inset 7
Stem Choose From: RaceFace Aeffect 50mm or RaceFace Turbine R35 50mm
Handlebar Choose From: RaceFace Aeffect 780/20 or RaceFace Turbine 800/20
Grips Choose From: Lizard Skins Charger Evo or Lizard Skins Machine
Seatpost Choose From:Fox Transfer Performance Elite, RockShox Reverb AXS or Fox Transfer Neo
Saddle Choose From: WTB Solano Cromoly or WTB Solano Titanium
Shifters SRAM AXS Pod Controller
Rotors SRAM HS2 180mm
Front Derailleur NA
Rear Derailleur SRAM XX T-Type Eagle AXS
Crankset SRAM GX Eagle - 32T
Cassette 10-52
Chain SRAM GX Eagle T-Type Flattop
Tires Choose From: Maxxis DHF 29 x 2.6 Front / Maxxis Rekon 29x2.4 Rear or Continental Kryptotal 29 x 2.6 Front / Continental Kryptotal 29 x 2.4 Rear
Wheelset Choose From: 29" i9 Sector Alloy or 29" DT Swiss XM 1700 Spline or 29" i9 Sector Carbon
Brakeset Sram Motive Silver
Fork Choose: FOX 36 Factory GripX 150mm, RockShox Lyrik 150mm, or Cane Creek Helm MKII 29"
Groupset Shimano XT Di2
Headset Choose From: Cane Creek Hellbender 70 or Chirs King Inset 8
Stem Choose From: RaceFace Aeffect 50mm or RaceFace Turbine R35 50mm
Handlebar Choose From: RaceFace Aeffect 780/20 or RaceFace Turbine 800/21
Grips Choose From: Lizard Skins Charger Evo or Lizard Skins Machine
Seatpost Choose From:Fox Transfer Performance Elite, RockShox Reverb AXS or Fox Transfer Neo
Saddle Choose From: WTB Solano Cromoly or WTB Solano Titanium
Shifters Shimano XT M8250
Rotors Shimano CL800 180mm
Front Derailleur NA
Rear Derailleur Shimano XT M8250 SGS
Crankset Shimano XT M8200 - 32T
Cassette 10-51
Chain Shimano M8100
Tires Choose From: Maxxis DHF 29 x 2.6 Front / Maxxis Rekon 29x2.4 Rear or Continental Kryptotal 29 x 2.6 Front / Continental Kryptotal 29 x 2.4 Rear
Wheelset Choose From: 29" i9 Sector Alloy or 29" DT Swiss XM 1700 Spline or 29" i9 Sector Carbon
Brakeset Shimano XT M8220
Fork Choose: FOX 36 Factory GripX 150mm, RockShox Lyrik 150mm, or Cane Creek Helm MKII 29"
Groupset SRAM Eagle XX
Headset Choose From: Cane Creek Hellbender 70 or Chirs King Inset 9
Stem Choose From: RaceFace Aeffect 50mm or RaceFace Turbine R35 50mm
Handlebar Choose From: RaceFace Aeffect 780/20 or RaceFace Turbine 800/22
Grips Choose From: Lizard Skins Charger Evo or Lizard Skins Machine
Seatpost Choose From:Fox Transfer Performance Elite, RockShox Reverb AXS or Fox Transfer Neo
Saddle Choose From: WTB Solano Cromoly or WTB Solano Titanium
Shifters SRAM AXS Pod Controller
Rotors SRAM HS2 180mm
Front Derailleur NA
Rear Derailleur SRAM GX T-Type Eagle AXS
Crankset SRAM XX EAGLE - 32T
Cassette 10-52
Chain SRAM XX Eagle T-Type Flattop
Tires Choose From: Maxxis DHF 29 x 2.6 Front / Maxxis Rekon 29x2.4 Rear or Continental Kryptotal 29 x 2.6 Front / Continental Kryptotal 29 x 2.4 Rear
Wheelset Choose From: 29" i9 Sector Alloy or 29" DT Swiss XM 1700 Spline or 29" i9 Sector Carbon
Brakeset Sram Motive Silver
Fork Choose: FOX 36 Factory GripX 150mm, RockShox Lyrik 150mm, or Cane Creek Helm MKII 29"
Groupset Shimano XTR Di2
Headset Choose From: Cane Creek Hellbender 70 or Chirs King Inset 10
Stem Choose From: RaceFace Aeffect 50mm or RaceFace Turbine R35 50mm
Handlebar Choose From: RaceFace Aeffect 780/20 or RaceFace Turbine 800/23
Grips Choose From: Lizard Skins Charger Evo or Lizard Skins Machine
Seatpost Choose From:Fox Transfer Performance Elite, RockShox Reverb AXS or Fox Transfer Neo
Saddle Choose From: WTB Solano Cromoly or WTB Solano Titanium
Shifters Shimano XTR M9250
Rotors Shimano CL900 180mm
Front Derailleur NA
Rear Derailleur Shimano XTR M9250 SGS
Crankset Shimano XTR M9220 - 32T
Cassette 10-51
Chain Shimano M9100
Tires Choose From: Maxxis DHF 29 x 2.6 Front / Maxxis Rekon 29x2.4 Rear or Continental Kryptotal 29 x 2.6 Front / Continental Kryptotal 29 x 2.4 Rear
Wheelset Choose From: 29" i9 Sector Alloy or 29" DT Swiss XM 1700 Spline or 29" i9 Sector Carbon
Brakeset Shimano XTR M9220
Fork Choose: FOX 36 Factory GripX 150mm, RockShox Lyrik 150mm, or Cane Creek Helm MKII 29"
Size XS S M L XL
A - Stack (cm) 65.1 65.4 66.1 67.9 69.3
B - Reach (cm) 38.5 42.5 45 47.5 49
C - Standover Height (cm) 76.9 78.5 78.6 83.1 87.2
D - Top Tube Length (cm) virtual horizontal 55.3 60 62.7 65.7 68.2
E - Seat Tube Angle 75.5° 75° 75° 75° 74.5°
F - Seat Tube Length (cm) 36.2 38.1 40 45.7 52
G - Head Tube Angle 64° 64.5° 64.5° 64.5° 65°
H - Head Tube Length (cm) 10 10.2 11.3 13.3 14.5
I - BB Drop (cm) 2.8 2.7 2.6 2.6 2.6
J - Front Center (cm) 72 75.6 78.5 81.9 83.3
K - Chainstay Length (cm) 445 445 445 445 445
L - Wheelbase (cm) 1156 1192 1223 1256 1271
M - Fork Offset (cm) 4.4 4.4 4.4 4.4 4.4
N - Trail (cm w/ 2.6" tire) 13.7 13.3 13.3 13.3 12.9
O - Fork Length (cm with a 150mm Fork) 555 555 555 555 555
XS
60cm 152 - 64cm 165
S
63cm 162 - 67cm 174
M
67cm 174 - 71cm 180
L
71cm 180 - 75cm 192
XL
74cm 189 - 77cm 198
