Spezia Frame

Name: Spezia Frame
Brand: Litespeed Bicycles
Price: 4395.0 USD
Availability: InStock
Rating: 5.00 (10 reviews)

The fastest, stiffest, and best-handling titanium road racer we’ve ever designed, built with an innovative sheet-formed 6AL/4V titanium top tube.

Component requests

Note any additional requests here

Your total:

USD

YOUR BUILD HIGHLIGHTS

ADVANTAGE OF MODERN PERFORMANCE

Every advantage that the Spezia represents is on full display; from the externally butted headtube to shaping. It’s all there for you to behold. The Spezia is finished with true modern performance geometry, a tire clearance of 35mm, and lowered chainstays.

THE TECHNOLOGY

The Spezia brings aerospace-grade titanium road bike construction to its absolute performance zenith. Our lightest disc brake road model—over 200 grams lighter than any other titanium disc brake road bike made today. All Spezia tubesets have wall thicknesses adjusted in-house to meet exacting size-specific parameters and precise weight standards.

6AL/4V HANDCRAFTED TOPTUBE

The centerpiece of the Spezia is a true Litespeed exclusive technology: our 6AL/4V sheet-multiformed titanium top tube. Handcrafted from a flat sheet into a tubeset, our 6AL/4V sheet top tube is lighter than a standard tube yet delivers greater tensile strength and lateral stiffness. The result is increased rigidity when climbing and sprinting, allowing for confident control on descents.

EXPLORE THE DETAILS

The Spezia is the successor to the legendary Litespeed T1sl, and it takes performance to the next level with an all-new tubeset designed to produce the highest stiffness-to-weight ever achieved in a titanium road bike.

Frame & Fork Specs

Frame

Frame Material	Superform SL 6/4 Titanium Tubeset (3AL/2.5V + 6AL/4V Top Tube)
Frame Weight	1,120g (Size M)
BB Standard	PF30 (T47 Optional Upgrade)
Seatpost Diameter	31.6mm
Derailleur Hanger	UDH
Front Derailleur Mount	34.9mm Clamp-on
Cable Routing	Semi-Integrated

Axle Specs

Front Spacing	12x100mm
Front Axle Spec	M12 x 1.5, 120-125mm
Rear Spacing	12x142mm
Rear Axle Spec	M12 x 1.0, 164-167mm

Drivetrain

Max Chainring Size (2x - Shimano)	54/40t
Max Chainring Size (2x - SRAM)	56/43t
Max Chainring Size (1x)	46t

Brakes

Rotor Max Size (Front)	160mm
Rotor Max Size (Rear)	160mm

Fork

Fork Offset	47mm
Rigid Fork Length	381mm

Tire Clearance

Max Tire Size	700 x 35mm

Mounts

Downtube Water Bottle Bolts	2
Seattube Water Bottle Bolts	2
Rack Mount	No


SIZE	XS	S	M	M/L	L	XL
A - STACK	52	53.5	55.5	58	61	64
B - REACH	37	37.5	38	39	39.5	40
C - STANDOVER HEIGHT (CM)	69.6	71.5	75	77	80	83.5
D - TOP TUBE LENGTH (CM) VIRTUAL HORIZONTAL	51.4	52.8	54.4	56.2	57.9	59.6
E - SEAT TUBE ANGLE	74.5°	74.0°	73.5°	73.5°	73.25°	73.0°
F - SEAT TUBE LENGTH (CM)	43	45	48	51	54	57
G - HEAD TUBE ANGLE	72.0°	72.5°	73.0°	73.0°	73.0°	73.0°
H - HEAD TUBE LENGTH (CM)	10.6	11.9	13.9	16.5	19.6	23.1
I - BB DROP (CM)	7.1	7.1	7.1	7.1	7.1	6.8
J - FRONT CENTER (CM)	57	57.5	58.1	59.9	61.3	62.4
K - CHAINSTAY LENGTH (CM)	41.5	41.5	41.5	41.5	41.5	41.5
L - WHEELBASE (CM)	97.4	97.9	98.60000000000001	100.4	101.8	103.3
M - FORK OFFSET (CM)	4.7	4.7	4.7	4.7	4.7	4.7

XS

147cm 58 - 157cm 62

S

157cm 62 - 165cm 66

M

165cm 66 - 175cm 69

ML

173cm 68 - 180cm 71

L

178cm 71 - 188cm 74

XL

188cm 74 - 198cm 76

When you select tubeless-ready wheels and tires, the bike will come from the Litespeed factory with tires set up tubeless with Stan's NoTubes sealant.

If you would like innertubes, you can make a note in the "component request field" on your order, and we will be happy to accommodate.

If you want confirmation whether your specific wheel/tire selection will come tubeless, feel free to contact us via email or chat.

2x maximum chainring size is 54/40t (Shimano) or 56/43t (SRAM). 1x maximum chainring size is 46t.

The Spezia is designed around 700c x 28mm-32mm tires. It has clearance to fit road tires up to 35mm wide.

Every Litespeed titanium frame is hand-built in the USA, in our factory in Chattanooga, Tennessee, by master framebuilders using premium, globally sourced materials.

The average lead time is 3-4 weeks. This is because every Litespeed titanium frame and complete bike is built to order. You will receive email updates informing you when we begin building and assembling your bike, and when it is shipped from our factory.

The Spezia is built with Litespeed's Superform SL 6/4 tubeset. Superform SL 6/4 is a superlight titanium tubeset that combines our 3AL/2.5V titanium Superform SL tubeset with a sheet-formed titanium top tube hand-crafted from a single ultra-thin sheet of 6AL/4V titanium. This is significantly lighter than a standard 3AL/2.5V top tube, while providing greater tensile strength and lateral stiffness for racing applications.

The Spezia is a road racing bike designed for road racing, crits, and general high-performance road riding.

The Spezia and Ultimate Disc have very similar race-oriented geometry and handling, but the Spezia is lighter and stiffer. The Arenberg has more upright, endurance-oriented geometry. The Arenberg is heavier, but provides more comfort and compliance.
