Gravel Ride For All

Flint

Read Reviews

Evolving from the iconic Watia, the Flint offers the titanium gravel versatility in an economical package. Off-road sessions with friends, epic race adventures, bikepacking, and more: the Flint is the sharpest blade in your quiver.

$3,395

Gravel Adventure & Race
Standard-Tier Shaped 3AL/2.5V Titanium Tubing
CNC-machined Headtube & BB
Universal Derailleur Hanger Design (UDH)

Climb and Sprint With Pure Energy


The Flint features 3AL/2.5V titanium, fabricated at our factory in Chattanooga, Tenn. using globally sourced materials. With a clean braceless seatstay design for full mud-shedding clearance, super clean cable routing, tons of tire clearance for sure footing, and more, take it all on—no matter the trail.

Delivers Optimal Strength-To-Weight


The Flint includes titanium dropouts, disc brake mount, headtube, and bottom bracket all designed and CNC machined in-house at Litespeed to deliver optimal strength-to-weight.

Ready For Your Next Gravel Adventure


Add loads of accessory options from rack mounts to nutrition and extra hydration/storage mounts, and you’re fully packed for your wildest long adventures. Stable without sacrificing agility, the Flint moves with ease where you want—when you want.

Second slide

Ignite Your Gravel Experience

Want To Know More?

Flint

$3,395.00 USD
Size Guide

Flint

Features

All the details on frame geometry, wheelsets, components, & more.

  • 3AL/2.5V titanium with size-specific tubesets, each with wall thickness controlled, drawn, and tuned per size
  • Titanium dropouts, disc brake mount, headtube, and bottom bracket designed, and CNC machined in-house at Litespeed to deliver optimal strength-to-weight
  • Dropped non-driveside chainstay for increased tire and chainring clearance
  • Universal Derailleur Hanger (UDH) design standard
  • Three bottle boss locations, including under downtube provided standard
  • Tire clearance up to 48mm (or 55mm on 650b tires)
  • Shift cable routing: Di2/AXS-specific internal or dual (Di2/AXS/Mechanical) external capability
  • PF30 bottom bracket shell, with T47 threaded
  • Litespeed vinyl graphics provided standard
  • Bright Brushed frame finish provided standard
  • TiDize color anodization or etched graphic upgrade available
  • Frame sizes: XS, S, M, ML, L, XL and custom
  • Proudly handcrafted in Chattanooga, TN using globally sourced premium materials
  • Average weight for size medium frame: 1,490 grams
  • Internally-routed rear brake housing

Component Kits

Every Litespeed is fully customizable and offeres multiple build kits, so you can meet your ride needs. If you seek more modifications, chat with our team to see how we can further customize your bike. Select a groupset...

Headset Select in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle Select in Builder
Shifters Shimano GRX RX810
Rotors Shimano MT800 160mm
Rear Derailleur Shimano GRX RX812
Crankset GRX RX810 1X 42T
Cassette Shimano XT M8000 11-40
Chain Shimano HG701
Bottom Bracket Praxis
Tires Select in Builder
Wheelset Select in Builder
Brakeset Shimano GRX RX810 Hydraulic
Fork Select in Builder
Headset Select in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle Select in Builder
Shifters Shimano GRX RX810
Rotors Shimano MT800 160mm
Front Derailleur Shimano GRX RX810
Rear Derailleur Shimano GRX RX810
Crankset GRX RX810 48/31
Cassette Ultegra 11-34
Chain Shimano HG701
Bottom Bracket Praxis
Tires Select in Builder
Wheelset Select in Builder
Brakeset Shimano GRX RX810 Hydraulic
Fork Select in Builder
Headset Select in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle Select in Builder
Shifters Shimano GRX RX820 12 spd
Rotors Shimano MT800 160mm
Rear Derailleur Shimano GRX RX822 12 spd
Crankset Shimano GRX RX820 1x 40T
Cassette Shimano XT M8100 10-51 12 spd
Chain Shimano M8100 12 spd
Bottom Bracket Praxis
Tires Select in Builder
Wheelset Select in Builder
Brakeset Shimano GRX RX820 Hydraulic
Fork Select in Builder
Headset Select in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle Select in Builder
Shifters Shimano GRX RX820 12 spd
Rotors Shimano XT MT800 160mm
Front Derailleur Shimano GRX RX820 12 Spd
Rear Derailleur Shimano GRX RX820 12 Spd
Crankset Shimano GRX RX820 48/31
Cassette Shimano Ultegra R8100 11-34T 12 spd
Chain Shimano M8100 12 spd
Bottom Bracket Praxis
Tires Select in Builder
Wheelset Select in Builder
Brakeset Shimano GRX RX820 Hydraulic
Fork Select in Builder
Headset Select in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle Select from above
Shifters Shimano GRX RX815 Di2
Rotors Shimano MT800 160mm
Rear Derailleur Shimano GRX RX817 Di2
Crankset GRX RX810 1X 42T
Cassette Shimano XT M8000 11-40
Chain Shimano HG701
Bottom Bracket Praxis
Tires Select in Builder
Wheelset Select in Builder
Brakeset Shimano GRX RX810 Hydraulic
Fork Select in Builder
Headset Select in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle Select in Builder
Shifters Shimano GRX RX815 Di2
Rotors Shimano MT800 160mm
Front Derailleur Shimano GRX RX815 Di2
Rear Derailleur Shimano GRX RX815 Di2
Crankset GRX RX810 48/31
Cassette Ultegra 11-34
Chain Shimano HG701
Bottom Bracket Praxis
Tires Select in Builder
Wheelset Select in Builder
Brakeset Shimano GRX RX810 Hydraulic
Fork Select in Builder
Headset Select in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle Select in Builder
Shifters SRAM Force D2 AXS HRD
Rotors SRAM Centerline X 160mm
Rear Derailleur SRAM Force D2 AXS XPLR 12spd
Crankset SRAM Force D2 1X 40T 12spd
Cassette SRAM Force XG 1271 XPLR 10-44 12spd
Chain SRAM Force Flattop 12spd
Bottom Bracket SRAM Press-Fit
Tires Select in Builder
Wheelset Select in Builder
Brakeset SRAM Force D2 HRD
Fork Select in Builder
Headset Select in Builder
Stem FSA Gossamer
Handlebar FSA NS Adventure Compact
Bar Tape Select in Builder
Seatpost FSA Gossamer
Saddle Select in Builder
Shifters SRAM Rival eTap AXS
Rotors SRAM Centerline X 160mm
Rear Derailleur SRAM Rival XPLR eTap AXS 12 spd
Crankset SRAM Rival 1X 42T 12 spd
Cassette SRAM Rival XPLR 10-44 12 spd
Chain SRAM Rival 12 spd
Bottom Bracket SRAM Press-Fit
Tires Select in Builder
Wheelset Select in Builder
Brakeset SRAM Rival eTap AXS HRD
Fork Select in Builder

Geometry

CM IN

Engineered with a lowered bottom bracket height, a bit longer wheelbase, and more capable stack and reach, the Flint delivers tuned stability for long days in the saddle. The Flint is Litespeed’s most versatile gravel ride yet.

  A - Top Tube Length B - Head Tube Angle C - Seat Tube Angle D - Seat Tube Length E - Chainstay Length F - BB Drop G - Wheelbase H - Front Center I - Fork Rake J - Standover Height K - Head Tube Length L - Stack M - Reach Stem Length (mm) Crank Length (mm)
XS 19.8 69.0° 75.0° 16.9 17.2 3.1 40.1 23.4 2.0 28.1 4.0 21.1 14.2 80 170
S 20.6 69.5° 74.5° 17.5 17.2 3.1 40.6 23.8 2.0 28.7 4.5 21.7 14.6 80 170
M 21.5 70.0° 74.0° 18.5 17.2 3.0 41.1 24.4 2.0 29.8 5.6 22.6 15.0 90 170
ML 22.4 70.5° 73.5° 19.5 17.2 3.0 41.7 24.9 2.0 30.9 6.5 23.6 15.4 90 170
L 22.8 71.0° 73.5° 20.5 17.2 2.9 42.0 25.3 2.0 32.0 7.6 24.6 15.6 110 175
XL 23.6 71.5° 73.0° 21.7 17.2 2.9 42.3 25.6 2.0 33.0 8.4 25.6 15.7 110 175
*GRX810 1X and 2X crank lengths:  XS, S, M, ML – 170   L & XL – 172.5
  A - Top Tube Length B - Head Tube Angle C - Seat Tube Angle D - Seat Tube Length E - Chainstay Length F - BB Drop G - Wheelbase H - Front Center I - Fork Rake J - Standover Height K - Head Tube Length L - Stack M - Reach Stem Length (mm) Crank Length (mm)
XS 50.3 69.0° 75.0° 43.0 43.7 7.8 101.9 59.4 5.0 71.4 10.1 53.5 36.0 80 170
S 52.3 69.5° 74.5° 44.5 43.7 7.8 103.0 60.5 5.0 73.0 11.5 55.0 37.0 80 170
M 54.5 70.0° 74.0° 47.0 43.7 7.6 104.5 62.0 5.0 75.8 14.1 57.5 38.0 90 170
ML 56.8 70.5° 73.5° 49.5 43.7 7.6 105.9 63.3 5.0 78.4 16.6 60.0 39.0 90 170
L 58.0 71.0° 73.5° 52.0 43.7 7.4 106.8 64.2 5.0 81.2 19.2 62.5 39.5 110 175
XL 60.0 71.5° 73.0° 55.0 43.7 7.4 107.5 64.9 5.0 83.8 21.4 65.0 40.0 110 175
*GRX810 1X and 2X crank lengths:  XS, S, M, ML – 170   L & XL – 172.5

Delivery & Support

Fully build and customize your Litespeed bike from the ground up. Build to your ride and specifications, where we then construct your ride in our shop, and ship direct to you!

×
