ULTIMATE G2 FI GRX 827 DI2 1X | SIZE LG

Name: Ultimate G2 Fi GRX 827 Di2 1x | Size LG
Brand: Litespeed Bicycles
Price: 6999.0 USD
Availability: InStock

Only One Available

$6,999.00 USD $6,999.00 MSRP $9,750.00

[LS-293] Ultimate G2 FI (LG, Shimano GRX 827 Di2 1x 12 Spd, Industry Nine 1/1 Alloy 2.0, Panaracer X1 - 50c Black, Cane Creek Invert CS 40mm, Jet Black, Cane Creek HCR, Selle Italia Novus Boost Evo Superflow, Tech Badge, Top Tube Mounts, Ti Seatpost - 0mm Offset - 380mm Length, FSA K-WING AGX Carbon Bar, 44cm, Cane Creek HCR Stem, 100mm, Chris King Threadfit T47 24i - Matte Black, 170mm, No Pedals)

In stock Out of stock

EXPLORE THE DETAILS

Frame & Fork Specs

Frame

Frame Material	Superform SL 3AL/2.5V Titanium Tubeset
Frame Weight	1,350g (Size M)
BB Standard	PF30 (T47 Optional Upgrade)
Seatpost Diameter	31.6mm
Derailleur Hanger	UDH
Front Derailleur Mount	34.9mm Clamp-on
Cable Routing	Fully-Integrated

Axle Specs

Front Spacing	12x100mm
Front Axle Spec	M12 x 1.5, 120-125mm
Rear Spacing	12x142mm
Rear Axle Spec	M12 x 1.0, 164-167mm

Drivetrain

Max Chainring Size (1x)	46t
Max Chainring Size (2x)	48/31t

Brakes

Rotor Max Size (Front)	180mm*
Rotor Max Size (Rear)	160mm

Fork

Fork Offset	50mm
Rigid Fork Length	420mm

Tire Clearance

1x	50mm**
2x	50mm**

Mounts

Downtube Water Bottle Bolts	2
Seattube Water Bottle Bolts	2
Toptube Bag Mount	Optional Upgrade
Downtube Accessory Mount	Yes
Rack Mount	Optional Upgrade

* Spec may vary with choice of front suspension.

** Spec may vary based on choice of front derailleur.


Size	XS	S	M	M/L	L	XL
A - Stack	55.3	55.7	56	58.5	61.5	64
B - Reach	36.4	37.3	39	39.5	40.5	41.5
C - Standover Height (cm)	71.7	72.7	75.7	79	81.3	84.5
D - Top Tube Length (cm) virtual horizontal	51.7	53.2	55.5	56.8	59	61
E - Seat Tube Angle	74.5°	74.0°	73.5°	73.5°	73.0°	73.0°
F - Seat Tube Length (cm)	43	44.5	47	49.5	52	55
G - Head Tube Angle	70.0°	71.0°	71.5°	71.5°	72.0°	72.0°
H - Head Tube Length (cm)	9.2	9.2	9.7	12.4	14.9	18.6
I - BB Drop (cm)	7.8	7.8	7.4	7.1	6.8	6.8
J - Front Center (cm)	59.6	59.6	61	62.3	63.6	65.7
K - Chainstay Length (cm)	42.5	42.5	42.5	42.5	42.5	42.5
L - Wheelbase (cm)	100.8	100.9	102.4	103.7	105.1	107.3
M - Fork Offset (cm)	5	5	5	5	5	5
N - Trail (cm w/ 45mm tire)	7.8	7.1	6.8	6.8	6.4	6.4

147cm 58 - 157cm 62

157cm 62 - 165cm 66

165cm 66 - 175cm 69

173cm 68 - 180cm 71

178cm 71 - 188cm 74

188cm 74 - 198cm 76

All Litespeed gravel bikes come from the factory with tires set up tubeless with Stan's NoTubes sealant.

If you would like innertubes, you can make a note in the "component request field" on your order, and we will be happy to accommodate.

Fork choice will depend on your riding preferences and terrain.

A gravel suspension fork will add comfort and confidence on rough terrain, but it will weigh more than a rigid carbon fork, and it may feel less efficient (due to flex, weight, or pedal bob) on smooth terrain.

A rigid fork is lighter, and it also provides a bit more tire clearance and mounting options for extra gear and bags, but it will transmit more shock from impacts and vibration from rough roads.

For more information on gravel suspension forks, read our detailed thoughts on gravel suspension here.

The Ultimate G2 is a gravel bike designed for tackling gravel terrain at high speeds. It is ideal for gravel riders who want a light and fast titanium gravel bike for a mix of racing, exploring, and general gravel riding.

The Toscano has similar geometry and handling, but its titanium tubeset is lighter and stiffer to suit more race-focused gravel riding. The Flint has a more relaxed, adventure-oriented geometry, more tire clearance, and a different tubeset, which makes it slightly heavier but provides more robustness and affordability.

1x maximum chainring size is 46t. 2x maximum chainring size is 48/31t.

The Ultimate G2 has clearance to fit gravel tires up to 700c x 50mm wide with both 1x and 2x drivetrains.

Every Litespeed titanium frame is hand-built in the USA, in our factory in Chattanooga, Tennessee, by master framebuilders using premium, globally sourced materials.

The average lead time is 3-4 weeks. This is because every Litespeed titanium frame and complete bike is built to order. You will receive email updates informing you when we begin building and assembling your bike, and when it is shipped from our factory.

The Ultimate G2 is built with Litespeed's Superform SL tubeset. Superform SL is a superlight titanium tubeset that sets the benchmark for advanced titanium bicycle tubes. Superform SL is an aerospace-grade 3AL/2.5V titanium tubeset that is custom-formed and hand-crafted in-house, allowing us to employ multi-dimensional shaping and variable wall-thickness to minimize weight and maximize performance.
