Fully-Integrated Gravel Performance

Ultimate G2 FI

Read Reviews

Looking for the fastest, highest-performance machine for race day? The Ultimate G2 FI is it. More tire clearance. More handling perfection. More engineered performance advantage. Now with Litespeed’s ultra-clean FI (Fully- Integrated) cockpit and cable routing design.

LIMITED TIME: GET 25% OFF!

AS LOW AS $4,758.75!

Performance Gravel Design
Pro-Tier Aggressively-Shaped 3AL/2.5V Titanium Tubing
Cable-Free Cockpit Design
T47i BB - Internal Routed System

A Visual Signature: Interlock Dropped Seatstays


By vertically dropping and widening the stays—and extending them past the seat tube to the top tube—the Ultimate G2 has two independent stiffness-enhancing weld points, resulting in an infinitely more responsive rear triangle, with stiffer out-of-saddle acceleration.

Fully Integrated


The Ultimate G2 Fi delivers more top-tier performance than ever. It's all finished with our premium fully- Integrated option; a handlebar, stem, fork, and bottom bracket system that allows for internal cable and wire routing. With no external housing, your Ultimate G2 FI becomes the cleanest rig on the start line.

Meticulously Shaped 3AL/2.5V Titanium Frame


With performance-focused titanium manipulation capabilities unique to Litespeed, the G2 showcases our unique in-house tube manipulation technologies on a level not seen in the industry. The result is a ride experience that rivals that of any titanium gravel bike out there.

Second slide

The Ultimate G2: Think Fast

Ultimate G2 FI

$6,345.00 USD
$4,758.75 $6,345.00
Size Guide

Ultimate G2 FI

Features

All the details on frame geometry, wheelsets, components, & more.

  • The Ultimate G2 redefines performance titanium gravel, with geometry changes designed to improve handling at speed, with current tire clearance capability and internal cable routing options.
  • Full Integration (FI) hides the brake housing and wiring within the integrated handlebar, stem, fork, and bottom bracket, tucking them cleanly out of the wind
  • Meticulously shaped and cold-worked 3AL/2.5V titanium frame
  • Interlock Dropped Seatstays, delivering exceptional rear triangle performance and exceptional tire clearance
  • CNC-machined titanium yoke (on driveside chainstay), increasing chainring and tire clearance
  • Lightweight butted headtube and bottom bracket shell
  • Full internal cable routing for both electronic and 1x mechanical build options*
  • Tire clearance up to 48mm* on 700c wheels**
  • Litespeed vinyl logos provided standard, including black and up to eight color choices to select from
  • Litespeed-specific truncated airfoil downtube, and multi-directional top tube for stiffness and precision handling
  • Threaded T47i bottom bracket standard keeps cables hidden within the bottom bracket shell
  • Bright Brushed frame finish with multiple decal color options available
  • Three bottle bosses (downtube, seattube and downtube underside) standard
  • TiDize color anodization upgrade available, including an additional anodized color-matched frame, headset and seat collar package options
  • Frame sizes: XS, S, M, ML, L, XL and custom
  • Proudly handcrafted in Chattanooga, TN using globally sourced premium materials
  • Average weight for size medium frame: 1,350 grams
  • Top tube storage and or rack mount options add-ons available
  • *2x mechanical builds require external front derailleur cable routing

    **Varies based on tire brand, tread and wheel combination

Component Kits

Every Litespeed is fully customizable and offeres multiple build kits, so you can meet your ride needs. If you seek more modifications, chat with our team to see how we can further customize your bike. Select a groupset...

Headset Select in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle Select in Builder
Shifters Shimano GRX RX825 Di2 12 spd
Rotors Shimano XT CL800 160mm
Front Derailleur Shimano GRX RX825 Di2
Rear Derailleur Shimano GRX RX825 Di2
Crankset Shimano GRX RX820 48/31
Cassette Shimano Ultegra R8100 11-34T 12 spd
Chain Shimano M8100 12 spd
Bottom Bracket Praxis
Tires Select in Builder
Wheelset Select in Builder
Brakeset Shimano GRX RX820 Hydraulic
Fork Select in Builder
Headset Select in Builder
Stem Select in Builder
Handlebar Select in Builder
Bar Tape Select in Builder
Seatpost FSA Gossamer
Saddle Select in Builder
Shifters SRAM Rival eTap AXS
Rotors SRAM Centerline X 160mm
Rear Derailleur SRAM Rival XPLR eTap AXS 12 spd
Crankset SRAM Rival 1X 42T 12 spd
Cassette SRAM Rival XPLR 10-44 12 spd
Chain SRAM Rival 12 spd
Bottom Bracket SRAM DUB T47
Tires Select in Builder
Wheelset Select in Builder
Brakeset SRAM Rival eTap AXS HRD
Fork Select in Builder
Headset Select in Builder
Stem Select in Builder
Handlebar Select in Builder
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle WTB Volt Medium Cromoly
Shifters SRAM Force D2 AXS HRD
Rotors SRAM Centerline X 160mm
Rear Derailleur SRAM Force D2 AXS XPLR 12spd
Crankset SRAM Force D2 1X 40T 12spd
Cassette SRAM Force XG 1271 XPLR 10-44 12spd
Chain SRAM Force Flattop 12spd
Bottom Bracket SRAM DUB T47
Tires Select in Builder
Wheelset Select in Builder
Brakeset SRAM Force D2 HRD
Fork Select in Builder
Headset Select in Builder
Stem Select in Builder
Handlebar Select in Builder
Bar Tape Select in Builder
Seatpost Select in Builder
Saddle WTB Volt Medium Cromoly
Shifters SRAM RED E1 AXS HRD
Rotors SRAM Paceline X 160mm
Rear Derailleur SRAM RED E1 AXS XPLR 13spd
Crankset SRAM RED E1 1X 42T Power Meter 13spd
Cassette SRAM RED XG 1391 XPLR 10-46 13spd
Chain SRAM RED
Bottom Bracket SRAM DUB
Tires Select in Builder
Wheelset Select in Builder
Brakeset SRAM RED E1 HRD
Fork Select in Builder

Geometry

CM IN

The Litespeed Ultimate G2 geometry is designed to improve handling at speed, with up to 48mm tire clearance capability and internal cable routing options.

  A - Top Tube Length B - Head Tube Angle C - Seat Tube Angle D - Seat Tube Length E - Chainstay Length F - BB Drop G - Wheelbase H - Front Center I - Fork Rake J - Standover Height K - Head Tube Length L - Stack M - Reach Stem Length (mm) Crank Length (mm)
XS 20.4 70.0° 74.5° 16.9 16.7 3.1 39.7 23.5 2.0 28.2 3.6 21.1 14.6 80 170
S 20.9 71.0° 74.0° 17.5 16.7 3.1 39.7 23.5 2.0 28.6 3.5 21.1 15.0 80 170
M 21.9 71.5° 73.5° 18.5 16.7 2.9 40.3 24.0 2.0 29.8 4.6 22.0 15.4 90 170
ML 22.4 71.5° 73.5° 19.5 16.7 2.8 40.8 24.5 2.0 31.1 5.6 23.0 15.6 90 170
L 23.2 72.0° 73.0° 20.5 16.7 2.7 41.4 25.0 2.0 32.0 6.6 24.2 15.9 110 175
XL 24.0 72.0° 73.0° 21.7 16.7 2.7 42.2 25.9 2.0 33.3 8.1 25.2 16.3 110 175
*GRX810 1X and 2X crank lengths:  XS, S, M, ML, L, XL – 170mm
  A - Top Tube Length B - Head Tube Angle C - Seat Tube Angle D - Seat Tube Length E - Chainstay Length F - BB Drop G - Wheelbase H - Front Center I - Fork Rake J - Standover Height K - Head Tube Length L - Stack M - Reach Stem Length (mm) Crank Length (mm)
XS 51.7 70.0° 74.5° 43.0 42.5 7.8 100.8 59.6 5.0 71.7 9.2 53.5 37.0 80 170
S 53.2 71.0° 74.0° 44.5 42.5 7.8 100.9 59.6 5.0 72.7 8.8 53.5 38.0 80 170
M 55.5 71.5° 73.5° 47.0 42.5 7.4 102.4 61.0 5.0 75.7 11.6 56.0 39.0 90 170
ML 56.8 71.5° 73.5° 49.5 42.5 7.1 103.7 62.3 5.0 79.0 14.3 58.5 39.5 90 170
L 59.0 72.0° 73.0° 52.0 42.5 6.8 105.1 63.6 5.0 81.3 16.8 61.5 40.5 110 175
XL 61.0 72.0° 73.0° 55.0 42.5 6.8 107.3 65.7 5.0 84.5 20.5 64.0 41.5 110 175
*GRX810 1X and 2X crank lengths:  XS, S, M, ML, L, XL – 170mm

Delivery & Support

Fully build and customize your Litespeed bike from the ground up. Build to your ride and specifications, where we then construct your ride in our shop, and ship direct to you!

×
