Premium Performance Gravel

Toscano

Read Reviews

The finest titanium gravel experience has arrived. A new frontier in riding pleasure and performance, engineered to push the envelope, every time.

LIMITED TIME: GET 25% OFF!

AS LOW AS $4,236.75!

Lightest Weight Performance Gravel Design
Elite-Tier 6AL/4V Multiform Titanium Top Tube
Lightweight Butted Headtube & BB
48mm Tire Clearance

Progressive Geometry


The Toscano is a purebred racer, through and through. That means a progressively longer reach paired with a shorter stem across the size range for a contemporary performance gravel experience. With tire clearance of 48mm, there’s plenty of clearance for tire volumes allowing you to go fast and far with pure traction and total comfort.

6AL/4V Titanium Handcrafted TopTube


With the DNA of our premium-tier Spezia road bike, we amalgamate all the performance aspects that are uniquely Litespeed into the Toscano, and our unique sheet-formed top tube is the star. A 6AL/4V flat titanium sheet is handcrafted into a tube, delivering greater tensile strength and lateral stiffness than a standard drawn tube, yet is much lighter.

Size Tuned Tubing


Every frame features tube diameters and wall thicknesses tuned to each specific frame size, as well as for the rigorous demands of gravel riding. Elegant elements you don’t see on other titanium bikes—an externally-butted headtube and bottom bracket, cosmetic elements like a badged headtube option, and a triaxially shaped downtube designed to deliver performance and aero advantages.

Second slide

Exceptional. Every Time. Everywhere

Toscano

$5,649.00 USD
$4,236.75 $5,649.00
Size Guide

Toscano

Features

All the details on frame geometry, wheelsets, components, & more.

  • The Toscano represents Litespeed’s flagship gravel experience, with a geometry and responsive handling that performs exceptionally at speed, with plenty of tire clearance and clean internal cable routing options
  • Lightest production non-integrated titanium disc brake gravel bike—1,360 grams (size medium)*
  • Litespeed’s hallmark sheet-formed 6AL/4V top tube, delivers unmatched stiffness, weight savings, and unparalleled handling advantage
  • Triaxially ovalized downtube shaped to deliver performance benefit, along with drag reduction advantage
  • Butted headtube and bottom bracket for weight savings
  • Dropped drive-side chainstay for increased chainring and tire clearance
  • Functionally ovalized-shaped seatstays
  • Titanium dropouts, head tube, and bottom bracket designed and machined in-house to deliver optimized strength-to-weight performance
  • Universal Derailleur Hanger (UDH) design standard
  • Tire volume capacity up to 48mm**
  • Shimano Di2 or SRAM eTap AXS-specific design
  • Toptube storage and or rack mount options add-ons available
  • Three bottle boss locations, including under downtube provided standard
  • Toscano Standard build: PF30 bottom bracket shell, with T47 threaded bottom bracket upgrade available
  • Bright Brushed frame finish provided standard, with multiple decal color options available
  • TiDize color anodization or etched graphic upgrade available
  • Frame sizes: XS, S, M, ML, L, XL and custom
  • Proudly handcrafted in Chattanooga, TN using globally sourced premium materials
  • **Varies based on tire brand, tread and wheel combination

Component Kits

Every Litespeed is fully customizable and offeres multiple build kits, so you can meet your ride needs. If you seek more modifications, chat with our team to see how we can further customize your bike. Select a groupset...

Headset Select in Builder
Stem FSA Gossamer
Handlebar FSA NS Adventure Compact
Bar Tape Select in Builder
Seatpost FSA Gossamer
Saddle Select in Builder
Shifters Shimano GRX RX810
Rotors Shimano CL800 160mm
Front Derailleur Shimano GRX RX810
Rear Derailleur Shimano GRX RX810
Crankset GRX RX810 48/31
Cassette Ultegra 11-34
Chain Shimano HG701
Bottom Bracket Praxis
Tires Select in Builder
Wheelset Select in Builder
Brakeset Shimano GRX RX810 Hydraulic
Fork Select in Builder
Headset Select Headset in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle Select in Builder
Shifters Shimano GRX RX820 12 spd
Rotors Shimano CL800 160mm
Rear Derailleur Shimano GRX RX822 12 spd
Crankset Shimano GRX RX820 1x 40T
Cassette Shimano XT M8100 10-51 12 spd
Chain Shimano M8100 12 spd
Bottom Bracket Praxis
Tires Select Tires in Builder
Wheelset Select Wheels in Builder
Brakeset Shimano GRX RX820 Hydraulic
Fork Select Fork in Builder
Headset Select Headset in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle Select in Builder
Shifters Shimano GRX RX820 12 spd
Rotors Shimano CL800 160mm
Front Derailleur Shimano GRX RX820 12 spd
Rear Derailleur Shimano GRX RX820 12 spd
Crankset GRX RX820 48/31
Cassette Ultegra R8100 11-34T 12 spd
Chain Shimano M8100 12 spd
Bottom Bracket Praxis
Tires Select Tires in Builder
Wheelset Select Wheels in Builder
Brakeset Shimano GRX RX820 Hydraulic
Fork Select Fork in Builder
Headset Select in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle Select in Builder
Shifters Shimano GRX RX825 Di2 12 spd
Rotors Shimano XT CL800 160mm
Front Derailleur Shimano GRX RX825 Di2
Rear Derailleur Shimano GRX RX825 Di2
Crankset Shimano GRX RX820 48/31
Cassette Shimano Ultegra R8100 11-34T 12 spd
Chain Shimano M8100 12 spd
Bottom Bracket Praxis
Tires Select in Builder
Wheelset Select in Builder
Brakeset Shimano GRX RX820 Hydraulic
Fork Select in Builder
Headset Select Headset in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon
Saddle Select in Builder
Shifters SRAM Force D2 AXS HRD
Rotors SRAM Centerline X 160mm
Rear Derailleur SRAM Force D2 AXS XPLR 12spd
Crankset SRAM Force D2 1X 40T 12spd
Cassette SRAM Force XG 1271 XPLR 10-44 12spd
Chain SRAM Force Flattop 12spd
Bottom Bracket SRAM Press-Fit
Tires Select Tires in Builder
Wheelset Select Wheels in Builder
Brakeset SRAM Force D2 HRD
Fork Select Fork in Builder
Headset Select Headset Above
Stem FSA Gossamer
Handlebar FSA NS Adventure Compact
Bar Tape Select in Builder
Seatpost FSA Gossamer
Saddle Select in Builder
Shifters SRAM Rival eTap AXS
Rotors SRAM Centerline X 160mm
Rear Derailleur SRAM Rival XPLR eTap AXS 12spd
Crankset SRAM Rival 1X 42T 12spd
Cassette SRAM Rival XPLR 10-44 12spd
Chain SRAM Rival 12spd
Bottom Bracket SRAM Press-Fit
Tires Select Tires in Builder
Wheelset Select Wheels in Builder
Brakeset SRAM Rival eTap AXS HRD
Fork Select Fork in Builder
Headset Select in Builder
Stem FSA Energy
Handlebar FSA A-Wing AGX Alloy
Bar Tape Select in Builder
Seatpost FSA SL-K Carbon or Titanium Seatpost
Saddle WTB Volt Medium Cromoly
Shifters SRAM RED E1 AXS HRD
Rotors SRAM Paceline X 160mm
Rear Derailleur SRAM RED E1 AXS XPLR 13spd
Crankset SRAM RED E1 1X 42T Power Meter 13spd
Cassette SRAM RED XG 1391 XPLR 10-46 13spd
Chain SRAM RED
Bottom Bracket SRAM DUB
Tires Select in Builder
Wheelset Select in Builder
Brakeset SRAM RED E1 HRD
Fork Select in Builder

Geometry

CM IN

The Toscano is a purebred racer, through and through. That means a progressively longer reach paired with a shorter stem across the size range for a contemporary performance gravel experience. With tire clearance of 48mm, there’s plenty of clearance for tire volumes allowing you to go fast and far with pure traction and total comfort.

  A - Top Tube Length B - Head Tube Angle C - Seat Tube Angle D - Seat Tube Length E - Chainstay Length F - BB Drop G - Wheelbase H - Front Center I - Fork Rake J - Standover Height K - Head Tube Length L - Stack M - Reach Stem Length (mm) Crank Length (mm)
XS 20.4 70.0° 74.5° 16.9 17.1 3.1 40.1 23.5 2.0 28.2 3.5 21.1 14.6 90 170
S 20.9 71.0° 74.0° 17.5 17.1 3.1 40.1 23.5 2.0 28.6 3.5 21.1 15.0 90 170
M 21.9 71.5° 73.5° 18.5 17.1 2.9 40.7 24.0 2.0 29.8 4.6 22.0 15.4 100 172.5
ML 22.4 71.5° 73.5° 19.5 17.1 2.9 41.2 24.5 2.0 31.1 5.6 23.0 15.6 100 172.5
L 23.2 72.0° 73.0° 20.5 17.1 2.7 41.8 25.0 2.0 32.0 6.6 24.2 15.9 110 175
XL 24.0 72.0° 73.0° 21.7 17.1 2.7 42.6 25.9 2.0 33.3 8.1 25.2 16.3 110 175
*GRX810 1X and 2X crank lengths:  XS, S, M, ML, L, XL – 170mm
  A - Top Tube Length B - Head Tube Angle C - Seat Tube Angle D - Seat Tube Length E - Chainstay Length F - BB Drop G - Wheelbase H - Front Center I - Fork Rake J - Standover Height K - Head Tube Length L - Stack M - Reach Stem Length (mm) Crank Length (mm)
XS 51.7 70.0° 74.5° 43.0 43.5 7.8 101.9 59.6 5.0 71.7 8.8 53.5 37.0 90 170
S 53.2 71.0° 74.0° 44.5 43.5 7.8 101.9 59.6 5.0 72.7 8.8 53.5 38.0 90 170
M 55.5 71.5° 73.5° 47.0 43.5 7.4 103.4 61.0 5.0 75.7 11.6 56.0 39.0 100 172.5
ML 56.8 71.5° 73.5° 49.5 43.5 7.4 104.7 62.3 5.0 79.0 14.3 58.5 39.5 100 172.5
L 59.0 72.0° 73.0° 52.0 43.5 6.8 106.2 63.6 5.0 81.3 16.8 61.5 40.5 110 175
XL 61.0 72.0° 73.0° 55.0 43.5 6.8 108.3 65.7 5.0 84.5 20.5 64.0 41.5 110 175
*GRX810 1X and 2X crank lengths:  XS, S, M, ML, L, XL – 170mm

Delivery & Support

Fully build and customize your Litespeed bike from the ground up. Build to your ride and specifications, where we then construct your ride in our shop, and ship direct to you!

×
