A hybrid designed to get you anywhere in style, with the low weight, high comfort, and effortless performance of Litespeed titanium.
Loading
YOUR BUILD HIGHLIGHTS
RELAXED GEOMETRY
With a straight handlebar for total control, an upright, relaxed geometry and quick handling capabilities on comfy 35mm tires, the Cherohala City can as easily maneuver through the hustle of the city streets as it can carve with speed through gravel city bike paths.
THE GO-TO COMMUTER CHOICE
Light and stiff, it also out-performs any alloy competitors. The American-made titanium frame using globally sourced premium materials, paired with a carbon fiber fork provides unmatched vibration damping. It’s a lively ride experience has to be experienced to be appreciated.
QUALITY AND FUNCTIONALITY
The Cherohala City not only takes you everywhere you want to go, it does so on a frame platform that’s truly second to none, with light weight performance, crisp handling, all with the organic durability and unmatched comfort that titanium delivers. The Cherohala City is your ticket to the finest possible urban riding experience.
EXPLORE THE DETAILS
Frame & Fork Specs
Frame
| Frame Material | Pure LW 3AL/2.5V Titanium Tubeset |
|---|---|
| Frame Weight | 1,467g (Size M) |
| BB Standard | PF30 (T47 Optional Upgrade) |
| Seatpost Diameter | 31.6mm |
| Derailleur Hanger | UDH |
| Front Derailleur Mount | 34.9mm Clamp-on |
| Cable Routing | Semi-Integrated |
Axle Specs
| Front Spacing | 12x100mm |
|---|---|
| Front Axle Spec | M12 x 1.5, 120-125mm |
| Rear Spacing | 12x142mm |
| Rear Axle Spec | M12 x 1.0, 164-167mm |
Drivetrain
| Max Chainring Size (2x) | 50/34t |
|---|---|
| Max Chainring Size (1x) | 50t |
Brakes
| Rotor Max Size (Front) | 160mm |
|---|---|
| Rotor Max Size (Rear) | 160mm |
Fork
| Fork Offset | 50mm |
|---|---|
| Rigid Fork Length | 395mm |
Tire Clearance
| Max Tire Size | 700 x 38mm |
|---|
Mounts
| Downtube Water Bottle Bolts | 2 |
|---|---|
| Seattube Water Bottle Bolts | 2 |
Select a build kit:
| Groupset | Shimano 105 Urban |
|---|---|
| Headset | Cane Creek 50 Series |
| Handlebar | FSA Comet 15 Riser Alloy |
| Bar Tape | ESI Chunky Grips |
| Seatpost | FSA Gossamer Alloy |
| Saddle | WTB Volt Medium Steel |
| Shifters | Microshift Trigger Shift |
| Rotors | Shimano RT70 160mm |
| Front Derailleur | N/A |
| Rear Derailleur | GRX RX810 11 Spd |
| Crankset | GRX RX810 40T |
| Cassette | 105 HG700 11-34 11Spd |
| Chain | Shimano LG500 11Spd |
| Bottom Bracket | Praxis or Upgradable to T47 |
| Tires | Panaracer Gravelking SS 35c |
| Wheelset | Select Option in Builder |
| Brakeset | TRP Mechanical Disc |
| Fork | Litespeed Carbon |
| Groupset | Ultegra Mechanical Urban |
|---|---|
| Headset | Cane Creek 50 Series |
| Handlebar | FSA Comet 15 Riser Alloy |
| Bar Tape | ESI Chunky Grips |
| Seatpost | FSA Gossamer Alloy |
| Saddle | WTB Volt Medium Cromoly |
| Shifters | Shimano Trigger Shifter |
| Rotors | Shimano CL800 160mm |
| Front Derailleur | N/A |
| Rear Derailleur | GRX RX810 11 Spd |
| Crankset | GRX RX810 40T |
| Cassette | Ultegra HG800 11-34 11Spd |
| Chain | Shimano LG500 11Spd |
| Bottom Bracket | Praxis or Upgradable to T47 |
| Tires | Panaracer Gravelking SS 35c |
| Wheelset | Select Option in Builder |
| Brakeset | Shimano RS600 Hydraulic Disc |
| Fork | Litespeed Carbon |
| Size | XS | S | M | M/L | L | XL |
|
The height of your bike’s cockpit. Bikes with taller stack height provide a more upright and comfortable riding position. Lower stack height provides a lower and more aggressive riding position.
|
n/a | 55 | 57.5 | 60 | 62.5 | 65 |
|
The length of your bike’s cockpit. Bikes with longer reach stretch you forward for a more aggressive riding position. Shorter reach shifts your weight back for a more relaxed riding position.
|
n/a | 37 | 37.5 | 38 | 38.5 | 39 |
|
The distance from the ground to the midpoint of the top tube. It’s good to have adequate clearance between the top tube and the base of your torso to make it easier to ride and come to a stop safely.
|
n/a | 73.4 | 76.9 | 79.7 | 82.5 | 85.8 |
|
A longer top tube will feel more stretched out. A shorter top tube will feel more compact. Top tube length can help determine fit, but stack and reach are the most reliable measures for modern bikes.
|
n/a | 52.3 | 53.4 | 55.2 | 57 | 58.9 |
|
A steeper (closer to 90°) seat tube angle moves the saddle forward to promote a more aggressive riding position. A slacker angle moves it backward for a more relaxed position. The seat angle of each bike is optimized for its intended riding style.
|
n/a | 74.5° | 74.5° | 74.0° | 73.5° | 73.0° |
|
Seat tube length is measured from the center of the BB to the top of the seat tube. Seat tube length can help determine bike fit, but it is most useful for determining how long your seatpost needs to be.
|
n/a | 46 | 49 | 52 | 55 | 58 |
|
A steeper (closer to 90°) head tube angle provides quick, responsive steering but less stability at high speeds. A slacker angle increases stability but can feel unresponsive at slow speeds. The head angle of each bike is optimized for its intended riding style.
|
n/a | 71.0° | 71.0° | 71.5° | 72.0° | 72.0° |
|
The length of the head tube will raise and lower a rider’s position on the bike, but stack height is a better measure for this. Head tube length is useful for determining how long your fork steerer needs to be.
|
n/a | 10.6 | 13.2 | 16.2 | 18.6 | 21.7 |
|
Increased BB drop lowers your center-of-gravity to improve stability for cornering and rough terrain. Reduced BB drop improves agility and clearance to avoid pedal strikes. The BB drop of each bike is optimized for its intended riding style.
|
n/a | 7.6 | 7.1 | 7.1 | 7.1 | 6.6 |
|
Measured from the center of BB to the center of the front axle. Lengthening the front center increases stability and can reduce toe overlap. Shortening the front center increases agility and can increase toe overlap.
|
n/a | 59.1 | 60.4 | 61.4 | 62.2 | 63.6 |
|
Shorter chainstays increase agility and allow riders to be more dynamic with their weight in corners. Longer chainstays increase stability at speed and over rough terrain. The chainstay lengths of each bike are optimized for its intended riding style.
|
n/a | 43 | 43 | 43 | 43 | 43 |
|
A shorter wheelbase increases agility and provides quicker handling. A longer wheelbase increases stability at high speeds and over rough terrain. The wheelbase of each bike is optimized for its intended riding style.
|
n/a | 100.9 | 102.4 | 103.4 | 104.2 | 105.7 |
|
Fork offset, or fork rake, affects trail. Less fork rake increases trail for slower handling but greater stability. More fork rake decreases trail for faster handling. The fork offset of each bike is optimized for its intended riding style.
|
n/a | 5 | 5 | 5 | 5 | 5 |
|
High Trail provides more stability at speed. Low trail provides faster, more agile steering. We optimize Trail for each bike by tuning our fork rakes and head angles to match the bike’s intended riding style.
|
n/a | 6.7 | 6.7 | 6.3 | 6 | 6 |
XS
S
M
ML
L
XL
147cm
58
-
157cm
62
157cm
62
-
165cm
66
165cm
66
-
175cm
69
173cm
68
-
180cm
71
178cm
71
-
188cm
74
188cm
74
-
198cm
76
