Pro-Tier Road

Ultimate Disc Frame

Read Reviews

The Ultimate exemplifies all the things required in a pro-level performance race bike. Light weight, aerodynamics, stiffness, compliance and the unsurpassed stopping power of disc brakes are all delivered in deftly-handcrafted titanium bike making it the most technically-advanced race machine available—anywhere.

LIMITED TIME: GET 25% OFF!

AS LOW AS $2,246.25!

Iconic Road Race Design
Pro-Tier Aggressively-Shaped 3AL/2.5V Titanium Tubing
Disc Brake Specific
30mm Tire Clearance
Overview Features Geometry Gallery Reviews
Second slide

The Ultimate: Two Wheeled Perfection

Ultimate Disc Frame

$2,995.00 USD
$2,246.25 $2,995.00
Size Guide

Ultimate Disc Frame

Features

All the details on frame geometry, wheelsets, components, & more.

  • High performance road/aero road
  • Full 3AL/2.5V titanium frame featuring Aeroform design with bladed seatstays for vertical compliance as well as aerodynamic benefit
  • Litespeed-specific truncated airfoil downtube, and quadrilaterally-formed top tube delivering stiffness and precision handling characteristics
  • Optimized for clearance on up to 30mm tires (most tire/rim combinations)
  • Lightweight, butted bottom bracket and head tube
  • Internal Di2 and hydraulic disc cable routing
  • Replaceable derailleur hanger
  • Bright Brushed Litespeed Finish option and decal option provided standard
  • Full range of custom paint upgrade options available
  • Custom component options available upon request
  • PF30 bottom bracket, with T47 bottom bracket upgrade available
  • Proudly handcrafted in Chattanooga, TN using globally sourced premium materials
  • Frame sizes: XS, S, M, ML, L, XL and custom
  • Average weight for size medium frame: 1,295 grams

Geometry

CM IN

Fresh engineering, considering the latest technology, the Ultimate has massive tire clearance, wind cheating aerodynamics, and ride quality that will keep you fresh for the final kilometers.

  A - Top Tube Length B - Head Tube Angle C - Seat Tube Angle D - Seat Tube Length E - Chainstay Length F - BB Drop G - Wheelbase H - Front Center I - Fork Rake J - Standover Height K - Head Tube Length L - Stack M - Reach Stem Length (mm) Crank Length (mm)
XS 20.3 72.0° 74.5° 17.9 16.3 2.8 38.2 22.3 1.8 28.2 4.0 20.3 14.6 90 -
S 20.7 72.5° 74.0° 18.7 16.3 2.8 38.4 22.5 1.8 28.9 4.5 20.9 14.8 90 -
M 21.3 73.0° 73.5° 19.5 16.3 2.8 38.6 22.7 1.8 29.6 5.1 21.5 15.0 100 -
ML 22.0 73.0° 73.0° 20.3 16.3 2.8 39.3 23.3 1.8 30.4 5.9 22.2 15.4 100 -
L 22.6 73.0° 73.0° 21.1 16.3 2.8 39.8 23.8 1.8 31.3 6.9 23.2 15.6 110 -
XL 23.2 73.0° 73.0° 21.9 16.3 2.7 40.3 24.4 1.8 32.3 8.1 24.4 15.7 110 -
  A - Top Tube Length B - Head Tube Angle C - Seat Tube Angle D - Seat Tube Length E - Chainstay Length F - BB Drop G - Wheelbase H - Front Center I - Fork Rake J - Standover Height K - Head Tube Length L - Stack M - Reach Stem Length (mm) Crank Length (mm)
XS 51.5 72.0° 74.5° 45.5 41.5 7.1 97.1 56.6 4.5 71.6 10.1 51.5 37.0 90 -
S 52.5 72.5° 74.0° 47.5 41.5 7.1 97.6 57.1 4.5 73.4 11.5 53.0 37.5 90 -
M 54.0 73.0° 73.5° 49.5 41.5 7.1 98.1 57.6 4.5 75.2 12.9 54.5 38.0 100 -
ML 56.0 73.0° 73.0° 51.5 41.5 7.1 99.7 59.2 4.5 77.2 15.0 56.5 39.0 100 -
L 57.5 73.0° 73.0° 53.5 41.5 7.1 101.0 60.5 4.5 79.5 17.6 59.0 39.5 110 -
XL 59.0 73.0° 73.0° 55.5 41.5 6.8 102.4 61.9 4.5 82.0 20.7 62.0 40.0 110 -

Delivery & Support

Fully build and customize your Litespeed bike from the ground up. Build to your ride and specifications, where we then construct your ride in our shop, and ship direct to you!

×
